Module: 2 | Teeth: 40
Please note: All products are sold individually, even if the image shows multiple items
Module: 2 | Teeth: 40
Subject to availability from the Manufacturer
Buy SSG2-40J20 | Spur Gears
Technical Specification:
SSG2-40J20
Precision Grade
JIS N7
Gear Teeth
Ground
Heat Treatment
Tooth surface induction hardened
Pressure Angle
20°
Tooth Hardness
50 - 60HRC
| Mat | Steel |
| Mat2 | S45C |
| Module | 2 |
| Teeth | 40 |
| Pitch | 80 |
| Bore | 20 |
| Bore2 | 20 keyway&screw hole |
| Bend | 98.28 |
| Surf | 72.11 |
| Tooth | High Precision |
| Keyway | Yes |
| Heat Treatment | Yes |
| Weight | 1.044 |
